Nortel SONET AccessNode 800A Series User Manual

Cabinet maintenance operations 12-39
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 12-10
Using the BIX or binding post test clips
This procedure explains how to use the BIX or binding post test clips that are
available for use with the BIX or binding post serving area interface.
The test clip is located on the right side of the swing frame in the termination
compartment (see Figure 12-8 on page 12-38).
Tools required
There are no special tools required to perform this procedure.
Action
Step Action
1 Connect the test set to the terminal end of the test cord.
2 Plug the test clip on the connector under test by pressing it against the pair
to be tested.
3 After testing is complete, pull out the clip and replace it on the side of the
swing frame.
—end—
