Cabinet maintenance operations 12-61
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 12-16 (continued)
Installing a new optional equipment fan shelf
Action
Step Action
1 Open the electronics compartment doors on the front side of the cabinet.
2 Locate the position of the fan shelf to be installed (see Figure 12-20).
Figure 12-20
Equipment fan shelf locations
FW-15239
—continued—
CDS 5
Cabinet
door
Shelf
spacer
Air
director
CDS 4
Fan
shelf (1)
CDS 3
CDS 2
CDS 1
CDS 7
CDS 6
ABM shelf
Fan shelf (2)
LCAP
BIP
FW-15239
