1-20 Installing the pad
AccessNode 323-3001-210 Issue 1.0
Procedure 1-1 (continued)
Preparing the poured-in-place cabinet mounting pad
Figure 1-12
AC pedestal, wide, anchor plate assembly (reference drawing EV7A52GA)
FW-15111
—continued—
Front
Anchor plate
Power end
Illustration of
"Elevated" pad
Illustration of
"Flat" pad
set-up
"Flat" pad
set-up
Cross rail angle
Anchor bolt
FW-15111
Anchor
bolt
Thread
protector
Flat washer
Cross rail
angle
Hex nut
Lock washer
Anchor
plate
