13-24 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Figure 13-15 shows the battery interface connectors on the rear left swing
frame adjacent to the BBP.
Figure 13-15
Battery interface connectors
FW-15155
Battery
interface
connectors
Battery cables
to strings 1-8
Battery cables
to strings 9-14
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Tie wraps
(4 places)
NT1W64AA
battery interface
cable to battery
breaker panel
Tie wraps
(8 places)
FW-15155
