Cabinet and equipment wiring and cabling 13-27
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Breaker interface panel circuit breaker designations
Table 13-6 shows the BIP breaker designations.
Table 13-6
BIP breaker designations
Breaker Amperage Designation
CE A 15A ABM shelf A A I/O cards
CE B 15A ABM shelf B A I/O cards
CDS1 PWR 15A CDS1 power converters
CDS2 PWR 15A CDS2 power converters
CDS3 PWR 15A CDS3 power converters
CDS4 PWR 15A CDS4 power converters
CDS5 PWR 15A CDS5 power converters
CDS6 PWR 15A CDS6 power converters
CDS7 PWR 15A CDS7 power converters
CE 1 1A ABM talk battery for TAC and MIC
CU A 15A Cooling unit plane A
CU B 15A Cooling unit plane B
CDS1 TB 10A CDS1 talk battery
CDS2 TB 10A CDS2 talk battery
CDS3 TB 10A CDS3 talk battery
CDS4 TB 10A CDS4 talk battery
CDS5 TB 10A CDS5 talk battery
CDS6 TB 10A CDS6 talk battery
CDS7 TB 10A CDS7 talk battery
