Cabinet and equipment wiring and cabling 13-37
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Local craft access panel (LCAP) wiring
Figure 13-24 shows the LCAP cable wiring block diagram to the ABM shelf
SIL (J02/J03) from the LCAP.
Figure 13-24
SIL J02/J03 LCAP cable wiring diagram
FW-15198
Orderwire extension wiring
Figure 13-25 shows the orderwire extension cable wiring block diagram to the
ABM shelf SIL (J04) from the LCAP shelf.
Figure 13-25
SIL J04 orderwire extension cable wiring diagram
FW-15199
LCAP1
J03
LCAP2
J02
NT4K1683
NT4K1684
Cables
p/o LCAP
J19
J00
J20
LCAP
NT4K16CA
ESD
Jack
ABM SIL
NT4K50AA
ABM
backplane
NT4K20AA
MIC
NT4K53AA
TST access
NT4K54AA
Filter
FW-15198
J19 J00
J4
Backplane connection
Filter
ABM SIL
NT4K50AA
ABM
backplane
NT4K20AA
MIC
NT4K53AA
To cross connect
for remote LCAP
and 4W VF to
orderwire connection
NT4K85TA
cable
FW-15199
