Cabinet and equipment wiring and cabling 13-39

AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0

MODEM wiring and cabling

Figure 13-27 shows the RS232 cable wiring block diagram to the MODEM

SIL (J08) from the modem.

Figure 13-27

SIL J08 modem cable wiring diagram

FW-15201

ABM SIL

NT4K50AA

ABM

backplane

NT4K20AA

MIC

NT4K53AA

J19 J00 Filter

NT4K86RA

cable

Modem

J50

APC

NT4K52

J08

FW-15201
