Cabinet and equipment wiring and cabling 13-43

AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0

Table 13-10 shows the E2A external alarm wire-wrap connections to the BIP.

Table 13-10

E2A external alarm connections

Signal name

E2A signal

name From To

FA XE2AR06 BBP FUSE-1 BIP PIN 9

FA RET XE2ARRET BBP FUSE-2 BIP PIN 8

RPTR FA XE2AR09 RPTR 1 POS23.14 BIP PIN 13

RPTR FA RET XE2ARRET RPTR 1 POS23.16 BIP PIN 11

RPTR LOS XE2AR10 RPTR 1 POS23.08 BIP PIN 15

RPTR LOS RET XE2ARRET RPTR 1 POS23.10 BIP PIN 11

RPTR ERR XE2AR11 RPTR 1 POS23.02 BIP PIN 16

RPTR ERR RET XE2ARRET RPTR 1 POS23.04 BIP PIN 14

RPTR FA XE2AR09 RPTR 2 POS23.14 BIP PIN 13

RPTR FA RET XE2ARRET RPTR 2 POS23.16 BIP PIN 14

RPTR LOS XE2AR10 RPTR 2 POS23.08 BIP PIN 15

RPTR LOS RET XE2ARRET RPTR 2 POS23.10 BIP PIN 17

RPTR ERR XE2AR11 RPTR 2 POS23.02 BIP PIN 16

RPTR ERR RET XE2ARRET RPTR 2 POS23.04 BIP PIN 17
