Table 13-21 shows the repeater shelf wiring and cabling for the
S800A cabinet.
Table 13-21
Repeater shelf cabling and wiring
From
Location Terminal Identification
To
Location Terminal
Repeater shelf 1
Repeater 1 Pin 02 RPTR ERR BIP pin field 16
Repeater 1 Pin 04 RPTR ERR RET BIP pin field 14
Repeater 1 Pin 08 RPTR LOS BIP pin field 10
Repeater 1 Pin 10 RPTR LOS RET BIP pin field 11
Repeater 1 Pin 14 RPTR FA BIP pin field 13
Repeater 1 Pin 16 RPTRFA RET BIP pin field 11
Shelf power (right side harness)
Repeater 2 Pin 01 -48V BBP CB 1
(-NEG 48V)
Repeater 2 Pin 02 RPTR ERR BIP pin field 16
Repeater 2 Pin 03 -48V RET BBP POS RTN 1
Repeater 2 Pin 04 RPTR ERR RET BIP pin field 17
Repeater 2 Pin 05 FFRM GND Frame ground
Repeater 2 Pin 08 RPTR LOS BIP pin field 15
Repeater 2 Pin 10 RPTR LOS RET BIP pin field 17
Repeater 2 Pin 14 RPTR FA BIP pin field 13
Repeater 2 Pin 16 RPTRFA RET BIP pin field 14
Miscellaneous power cabling
BIP CU A/B NT1W87AB
(W, BK) Fan group 1
(RED, BK) Fan group 2
NT7A6980/82
(W, BK)
(RED, BK)
Roof fan
power (+/-)
BIP CU A/B NT1W87AB
(W, BK)
(RED, BK)
Power connector
Fan shelf 1
Fan shelf 2
Fan shelf
power (+/-)
