13-78 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
SPC VF-4 P13 CDS 4
(NT1W87BD/BG)
SPC 4 Pairs 01–25 289–313
SPC VF-4 P14 CDS 4
(NT1W87BD/BG)
SPC 4 Pairs 26–50 314–338
SPC VF-4 P15 CDS 4
(NT1W87BD/BG)
SPC 4 Pairs 51–75 339–363
SPC VF-4 P16 CDS 4
(NT1W87BD/BG)
SPC 4 Pairs 76–96 364–384
SPC VF-5 P17 CDS 5
(NT1W87BD/BG)
SPC 5 Pairs 01–25 385–409
SPC VF-5 P18 CDS 5
(NT1W87BD/BG)
SPC 5 Pairs 26–50 410–444
SPC VF-5 P19 CDS 5
(NT1W87BD/BG)
SPC 5 Pairs 51–75 445–459
SPC VF-5 P20 CDS 5
(NT1W87BD/BG)
SPC 5 Pairs 76–96 460–480
SPC VF-6 P21 CDS 6
(NT1W87BE/BH)
SPC 6 Pairs 01–25 481–505
SPC VF-6 P22 CDS 6
(NT1W87BE/BH)
SPC 6 Pairs 26–50 506–530
SPC VF-6 P23 CDS 6
(NT1W87BE/BH)
SPC 6 Pairs 51–75 531–555
SPC VF-6 P24 CDS 6
(NT1W87BE/BH)
SPC 6 Pairs 76–96 556–576
SPC VF-7 P25 CDS 7
(NT1W87BF/BJ)
SPC 7 Pairs 01–25 577–601
SPC VF-7 P26 CDS 7
(NT1W87BF/BJ)
SPC 7 Pairs 26–50 602–626
SPC VF-7 P27 CDS 7
(NT1W87BF/BJ)
SPC 7 Pairs 51–75 627–651
SPC VF-7 P28 CDS 7
(NT1W87BF/BJ)
SPC 7 Pairs 76–96 652–672
—end—
Table 13-20 (continued)
SPC/CDS VF cabling and wiring
From
Location Terminal Identification
To
Location Terminal
VF line
number
