Nortel SONET AccessNode 800A Series User Manual

Cabinet and equipment wiring and cabling 13-77
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Table 13-20 shows the SPC to CDS VF cabling and wiring for the
S800A cabinet.
The last four pairs (22–25) in the VF cable from each CDS VF connector
76–96 are not used. Protector block positions 97-100 are unused in S800A
applications.
VF cables NT1W87BD, NT1W87BE and NT1W87BF are used to connect to
the NT4K12AA CDS shelf. VF cables NT1W87BG, NT1W87BH and
NT1W87BJ are used to connect to the NT4K12AB CDS shelf.
Table 13-20
SPC/CDS VF cabling and wiring
From
Location Terminal Identification
To
Location Terminal
VF line
number
SPC VF-1 P1 CDS 1
(NT1W87BD/BG)
SPC 1 Pairs 01–25 01–25
SPC VF-1 P2 CDS 1
(NT1W87BD/BG)
SPC 1 Pairs 26–50 26–50
SPC VF-1 P3 CDS 1
(NT1W87BD/BG)
SPC 1 Pairs 51–75 51–75
SPC VF-1 P4 CDS 1
(NT1W87BD/BG)
SPC 1 Pairs 76–96 76–96
SPC VF-2 P5 CDS 2
(NT1W87BD/BG)
SPC 2 Pairs 01–25 97–121
SPC VF-2 P6 CDS 2
(NT1W87BD/BG)
SPC 2 Pairs 26–50 122–146
SPC VF-2 P7 CDS 2
(NT1W87BD/BG)
SPC 2 Pairs 51–75 147–171
SPC VF-2 P8 CDS 2
(NT1W87BD/BG)
SPC 2 Pairs 76–96 172–192
SPC VF-3 P9 CDS 3
(NT1W87BD/BG)
SPC 3 Pairs 01–25 193–217
SPC VF-3 P10 CDS 3
(NT1W87BD/BG)
SPC 3 Pairs 26–50 218–242
SPC VF-3 P11 CDS 3
(NT1W87BD/BG)
SPC 3 Pairs 51–75 243–267
SPC VF-3 P12 CDS 3
(NT1W87BD/BG)
SPC 3 Pairs 76–96 268–288
—continued—
