13-76 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Table 13-19 shows the miscellaneous cabling and wiring for the
S800A cabinet.
Table 13-19
Miscellaneous cabling and wiring
From
Location Terminal Identification
To
Location Terminal
Roof fans Fan alarm leads Blue wire lead BBP Pin 7 FAN
Fan shelf 1 Connector position 3 NT1W87AB
P4.3
Fan alarm lead
BBP Pin 9 FAN
Fan shelf 2 Connector position 3 NT1W87AB
P5.3
Fan alarm lead
BBP Pin 9 FAN
RPTR 1 ABM I/O card NT4K85UA
RPTR 2 ABM I/O card NT4K85UA
DC distribution shelf SPG Cabinet ground bar Cabinet ground
bar
NT1W87BB
Rectifier shelf FG Frame ground Frame ground NT4K84YB
DC distribution shelf FG Frame ground Frame ground NT4K84YB
DC distribution shelf SPG Cabinet ground bar Cabinet ground
bar
NT1W87BB
