Cabinet and equipment wiring and cabling 13-75
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
BIP CDS PWR1 CDS 1 power right side
(NT1W84AB)
CDS 1 PWR
BIP CDS PWR2 CDS 2 power right side
(NT1W84AB)
CDS 2 PWR
BIP CDS PWR3 CDS 3 power right side
(NT1W84AB)
CDS 3 PWR
BIP CDS PWR4 CDS 4 power right side
(NT1W84AB)
CDS 4 PWR
BIP CDS PWR5 CDS 5 power right side
(NT1W84AB)
CDS 5 PWR
BIP CDS PWR6 CDS 6 power right side
(NT1W84AC)
CDS 6 PWR
BIP CDS PWR7 CDS 7 power right side
(NT1W84AC)
CDS 7 PWR
BIP CE PWR A ABM CE PWR Connector NT1W84AA
BIP CE PWR B ABM CE PWR Connector NT1W84AA
BIP J15 CU PWR A Roof fan group 1
Fan shelf 1
power/ret. (+/-)
BIP J16 CU PWR B Roof fan group 2
Fan shelf 2
power/ret. (+/-)
—end—
Table 13-18 (continued)
BIP alarm and power cabling and wiring
From
Location Terminal Identification
To
Location Terminal
