13-74 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Miscellaneous cabling
BIP CTRL CE 1 NT1W85AA ABM BIP CTL (J13)
Power cabling
BIP Batt1/Ret1 -48V (NT1W87DA) DC distribution shelf BIP -48V (BR1)
BIP Batt2/Ret2 -48V (NT1W87DA) DC distribution shelf BIP -48V (BR2)
BIP Batt3/Ret3 -48V (NT1W87DA) DC distribution shelf BIP -48V (BR3)
BIP Batt4/Ret3 -48V (NT1W87DA) DC distribution shelf BIP -48V (BR4)
BIP CDS TB1 CDS 1 power left side
(NT1W84AB)
CDS 1 TB
BIP CDS TB2 CDS 2 power left side
(NT1W84AB)
CDS 2 TB
BIP CDS TB3 CDS 3 power left side
(NT1W84AB)
CDS 3 TB
BIP CDS TB4 CDS 4 power left side
(NT1W84AB)
CDS 4 TB
BIP CDS TB5 CDS 4 power left side
(NT1W84AB)
CDS 5 TB
BIP CDS TB6 CDS 6 power left side
(NT1W84AC)
CDS 6 TB
BIP CDS TB7 CDS 7 power left side
(NT1W84AC)
CDS 7 TB
—continued—
Table 13-18 (continued)
BIP alarm and power cabling and wiring
From
Location Terminal Identification
To
Location Terminal
