2-12 Installing the cabinet
AccessNode 323-3001-210 Issue 1.0
Procedure 2-2 (continued)
Preparing the pad
Step Action
3 Remove and save the plastic cap plugs, nuts, washers and support angles
from the anchoring bolts on the mounting pad.
4 Clear the pad of any debris and make sure that the pad is level and free of
obstructions.
5 Place the appropriate sealant kit pieces (see Table 2-5 and Figure 2-5) from
anchor plate sealant kit into position on the pad after removing the paper
backing.
6 Ensure that all sealant kit cutouts are aligned with the pad conduits and that
each piece lies flat on the pad with no wrinkling or folded edges.
Note:
Middle section sealant pieces must be placed with the untreated edge
(the paper lip having no sealant material attached) toward the outside edge
of the pad so that the treated edges butt up against each other in the center
of the pad.
7 Reinstall the red protective cap plugs on the cabinet anchor bolts in the
concrete pad.
—continued—
CAUTION
Install the anchor plate sealant kit
The anchor plate sealant kit must be installed before the
cabinet is lifted onto the mounting pad. Improper
installation of the sealant kit may result in galvanic
corrosion damage to the cabinet.
Table 2-5
Pad/sealant kit (P0738444)
Pad
QTY
P0738460
middle
sections
QTY
P0738461
ac side
sections
QTY
P0738462
ac side
sections
QTY
P0738463
termination side
sections
P0729558 2 1 1
P0729559 2 1 1
P0729560 2 1 1
P0729561 2 1 1
