2-26 Installing the cabinet
AccessNode 323-3001-210 Issue 1.0
Procedure 2-4 (continued)
Mounting the cabinet on the pad
Step Action
5 Position the two Durometer rubber pad strips where the left and right bolt
openings in the ac pedestal (if installed) will sit on the concrete pad (see
Figure 2-12 on page 2-27.
6 Observe the cabinet-to-pad alignment as the cabinet is lowered to the pad.
7 Lower the cabinet into place on the pad using the following precautions:
• Align the conduits with the proper cabinet conduit entry holes.
• Align the ac entry conduit in the pad (with the coupling attached) with the
ac entry conduit inside of the ac pedestal, if installed.
• Align one Durometer pad on the right side of the enclosure, and the other
pad on the left side of the enclosure (see Figure 2-12 on page 2-27).
8 Ensure that the cabinet sits securely on the pad and is fully seated on all
anchor bolts (see Figure 2-13 on page 2-28).
9 Check leveling with a spirit level.
10 Place shims under the edge of the cabinet if required for leveling. If shims are
used, caulk the cabinet-to-pad interface.
Note:
Use caulking completely around the cabinet bottom as per local
practices for material and workmanship.
—continued—
CAUTION
Possible cabinet misalignment
Using shims to level the cabinet can cause the doors or
swing bays to become misaligned. Use shims only as
necessary.
