15.3 Bit Mapping Rules
The bit mapping for a G3 manifold varies with the physical configuration of the manifold. The following is a breakdown of the
bit mapping rules associated with the Numatics valve manifold.
Valve Side
1) Solenoid coil outputs are connected to the valve coils using the Z-Boards
™
.
2) The valve solenoid coil output portion of the total output size is fixed at 4 bytes.
3) Each solenoid coil output has an associated status input bit (refer to the section labeled, “Output Short Circuit
Protection”, on page 26 for functional details). The solenoid coil status input size is fixed at 4 bytes.
4) Solenoid coil output addressing begins at the 1
st
manifold station nearest the node using “14” coil 1
st
and then, if
applicable, the “12” coil, and continues in ascending order away from the communication node.
5) Each manifold station allocates 1 or 2 output bits. This is dependent on the Z-Board
™
type installed.
A single Z-Board
™
allocates 1 output bit. A double Z-Board
™
allocates 2 output bits.
6) Z-Boards
™
can be used in any arrangement (all singles, all doubles, or any combination) as long as output group
No.1 and output group No. 2 bits do not overlap (i.e. combinations of Z-Boards
™
could exist where the physical
configuration of the manifold could exceed the output capacity.
Discrete I/O Side
Outputs
1) The Sub-Bus output byte size portion is self-configuring in byte increments, after an output module is installed on
the Sub-Bus and power is applied.
2) Outputs are mapped consecutively by module. The output bits from the 1
st
module will be mapped directly after
the bits from the valve coils. The output bits from the second module will be mapped directly after the output bits
from the 1
st
module and so on.
Inputs
1) The Sub-Bus input byte size portion is self-configuring in byte increments, after an input module is plugged into
back plane and power is applied.
2) Inputs are mapped consecutively by module. The input bits from the 1
st
module will be mapped directly after the
status bits from the valve side. The input bits from the second module will be mapped directly after the input
bits from the 1
st
module and so on.
3) All of the modules have associated internal status bits, which will affect the total value of input bytes..
4) When a module has discrete and status inputs, the status bits are mapped after the discrete input bits.
