8. Digital I/O Module
8.1 Digital I/O Module Usage
The maximum number of modules that can be used on the Discrete I/O side of the manifold is 16. These modules can
be centralized on the main fieldbus manifold, distributed or a combination of both. Modules can be connected in any
combination of inputs, outputs and specialty up to the physical limitation of 16 modules.
Input Module Types
Output Module Types
Input/Output Module Types Valve Side Output Module Types
