10.2 Analog Graphic Display
The G3 Analog I/O modules have an integrated graphic display that may be used to configure the parameters of the modules
as well as show diagnostic information. Please see the following pages for detailed information regarding these displays.
I/O MAPPING
INPUT BYTE XX
I/O MAPPING
OUTPUT BYTE XX
MODULE NUMBER
XX
ALARM SETTINGS
DESCRIPTION
2AI/2AO
PART NUMBER
240-2XX
FIRMWARE
V2.XXX
SET BRIGHTNESS
MEDIUM
SET SELF TEST
FACTORY
DEFAULTS
HELP
