I/O Mapping Examples
Manifold I/O Configuration
Pos
No.
Module Type
Part No.
In
Out
Diag
Bytes
Diagnostic Word
0
0
2
Local Valve Size
0
8
8
Total:
0
8
10
Assumed Settings
15.4 Example No. 1
(501 Valves with 60 coils)
- Double Z-Boards
TM
used with all valves
- I/O Modules and mapping schemes are identified
by their corresponding color.
When the 14 end
Solenoid is
energized,
the 4 port
is pressurized
When the 12 end
Solenoid is
energized,
the 2 port
is pressurized
Valve Coil
Number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
60
