8.6 Digital Input/Output Modules
Two Digital I/O per Connector - 12mm Female Modules
Module Part No.
I/O Type
Short Circuit
Protection
Short Circuit
Protection Status
Bits
Output
Points
Input
Points
240-211
PNP (Sourcing)
YES – Visual
YES (8) – Optional
8
8
Output Mapping
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
(Required)
Output 7
Output 6
Output 5
Output 4
Output 3
Output 2
Output 1
Output 0
Input Mapping
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
(Required)
Input 7
Input 6
Input 5
Input 4
Input 3
Input 2
Input 1
Input 0
Diagnostics
X
Allocate
d and
Reserve
d
Allocate
d and
Reserve
d
Allocate
d and
Reserve
d
Allocate
d and
Reserve
d
Conn. D
SCP
Status
Conn. C
SCP
Status
Conn. B
SCP
Status
Conn. A
SCP
Status
X+1
Output 7
Status
Bit
Output 6
Status
Bit
Output 5
Status
Bit
Output 4
Status
Bit
Output 3
Status
Bit
Output 2
Status
Bit
Output 1
Status
Bit
Output 0
Status
Bit
