Numatics G3 Series - Power Consumption

G3 Series EtherNet/IP
TM
DLR Technical Manual
4-24
TDG3EDM1-6EN 3/18
Subject to change without notice
www.asco.com/g3
4.6 Power Consumption
Power Connection
CENELEC
Pin No.
Function
Description
1
+24 VDC
(Valves and Outputs)
Voltage used to power outputs
(valve coils and discrete outputs) SW
2
+24 VDC
(Node and Inputs)
Voltage used to power discrete inputs and
module electronics UNSW
3
0 VDC Common
(Node and Inputs)
0 VDC (-V) Voltage used to power discrete inputs and
node electronics UNSW
4
0 VDC Common
(Valves and Outputs)
0 VDC (-V) Voltage used to power outputs
(valve coils and discrete outputs) SW
Power Rating
• For maximum supply current capability please refer to page 61.
• Loads should not draw more than 0.5 Amps of current from any one individual discrete output point (Contact
factory for higher current capability requirements).
CHART 1
Component
Voltage
Tolerance
+24VDC
(Valves and Outputs)
Pins 1 and 4
+24VDC
(Node and Inputs)
Pins 2 and 3
Current
Power
Current
Power
Solenoid Valve Coil 501 (Each)
24 VDC
+10%/-15%
0.03 A
0.80 W
0 A
0 W
Solenoid Valve Coil 503 (Each)
24 VDC
+10%/-15%
0.07 A
1.70 W
0 A
0 W
Solenoid Valve Coil 2002 (Each)
24 VDC
+10%/-15%
0.02 A
0.48 W
0 A
0 W
Solenoid Valve Coil 2005 (Each)
24 VDC
+10%/-15%
0.06 A
1.44 W
0 A
0 W
Solenoid Valve Coil 2012 (Each)
24 VDC
+10%/-15%
0.11 A
2.64 W
0 A
0 W
Solenoid Valve Coil 2035 (Each)
24 VDC
+10%/-15%
0.11 A
2.64 W
0 A
0 W
Solenoid Valve Coil ISO 5599/2- SPA
24 VDC
+10%/-15%
0.17 A
4.08 W
0 A
0 W
Valve Adapter (Driver) 2000 series
24 VDC
+/- 10%
0.03A
0.72 W
0.02 A
0.48 W
Valve Adapter (Driver) 500 series
24 VDC
+/- 10%
0.03A
0.72 W
0.02 A
0.48 W
501 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
502 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
503 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
Digital Module
24 VDC
+/- 10%
0.04 A
0.96 W
0.05 A*
1.20 W*
Analog Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.08 A*
1.92 W*
Sub-Bus Hub
24 VDC
+/- 10%
0 A
0 W
0.06 A
1.44 W*
RTD Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.06 A
1.44 W*
Communication Module (Node)
24 VDC
+/- 10%
0.01 A
0.24 W
0.10 A*
2.40 W*
Sub-Bus Valve Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.03 A*
0.72 W*
Auto Recovery Module (ARM)
24 VDC
+/- 10%
0 A
0 W
0.03 A
0.72 W
* Current depends on graphic display brightness setting. Max. value shown with high brightness.
Values decrease by approx. 5% for Medium and 11% for Low brightness settings.
• Total power consumption for each Discrete I/O point is dependent on the
specific current draw of input sensor devices and output loads.
NOTE!
