Numatics G3 Series - 501 Series: Up to 64 Solenoid Coils

G3 Series EtherNet/IP
TM
DLR Technical Manual
9-87
TDG3EDM1-6EN 3/18
Subject to change without notice
www.asco.com/g3
9.8 501 Series, up to 64 solenoid coils
501 series, 4 station manifold block with an integrated 32 coil valve driver
• To be used with 501 series valves on valve manifold assemblies with 33-64 coils.
• Only to be used on assemblies where additional power, supply and/or exhaust capacity is not required
Integrated 32 coil valve driver
Byte X
Byte X+1
Byte X+2
Byte X+3
Byte X+4
Byte X+5
Byte X+6
Byte X+7
