5.16 Advanced Settings – Compatibility Mode
This allows the enabling / disabling of the “Compatibility Mode”. Compatibility mode sets the Ethernet IP/DLR module
configuration to operate as a standard Ethernet IP (non DLR) node.
Compatibility Mode Settings
15. Press the SET button to enter the ADVANCED SETTINGS
menu.
16. Press the NEXT button to scroll to the ADVANCED MENU /
COMPAT MODE
17. Press the SET button to enter the COMPAT MODE menu
18. Press the SET button, the current state of the parameter is
highlighted.
19. Press the SET button to change this parameter
d. DISABLED menu)
e. ENABLED
f. RETURN (this will return to the main menu )
20. Press the SET button to confirm your choice
Press the NEXT button to select Yes or No to accept the
selection
Press the SET button to confirm your choice
c. Selecting No will bring you back to the main COMPAT
MODE menu.
d. Selecting Yes will take you to the following save
settings menu.
Save Settings Steps
21. Press the NEXT button to select either NOW or LATER.
Press the SET button to confirm your choice.
c. Selecting NOW will cause the node to reset and apply
the new setting
d. Selecting LATER will cause the new COMPAT MODE
selection to be saved in memory, you must Accept
the saved changes before your next power cycle
otherwise they will be lost.
