Numatics G3 Series - Example No. 3; Example No. 4

G3 Series EtherNet/IP
TM
DLR Technical Manual
15-149
TDG3EDM1-6EN 3/18
Subject to change without notice
www.asco.com/g3
Manifold I/O Configuration
Pos.
No.
Module Type
Part No.
In
Out
Diag
Bytes
Diagnostic Word
0
0
2
Local Valve Size:
0
4
4
Total:
0
4
6
How to Order
Qty
Part Number
1
AK3EF00003NDRM
3
051BA4Z2MN00061
3
051BB4Z2MN00061
1
G3EP100R0G32
ASSEMBLED
When the 14 End
Solenoid is
energized, the 4 port
is pressurized
When the 12 End
Solenoid is
energized, the 2 port
is pressurized
0
2
4
6
8
10
1
3
5
7
9
11
Valve Coil
Number
Assumed Settings
16.5 Example No. 2
- Double Z-Boards
TM
used with all valves
- I/O Modules and mapping schemes are
identified by their corresponding color.
- I/O Status bits are enabled
- Diagnostic Word is enabled
