Here are some basic wiring examples of Straight-Through cabling. Crossover cabling is not required for the G3
Ethernet IP DLR module.
EtherNet/IP
TM
Cabling Diagram
NOTE!
• These are examples only. For appropriate network cabling information, please see
the ODVA document titled, “Ethernet/IP
TM
: Media Planning and Installation
Manual”.
• RJ45 shown as T-568B standard.
STRAIGHT-THROUGH
CABLE
6
3
2
1
RX- (GREEN)
RX+ (WHITE/GREEN)
TX- (ORANGE)
TX+ (WHITE/ORANGE)
MALE
6
3
2
1
MALE
RX- (GREEN)
RX+ (WHITE/GREEN)
TX- (ORANGE)
TX+ (WHITE/ORANGE)
RJ45 to RJ45 Cable
STRAIGHT-THROUGH
CABLE
MALE
2
3
4
1
RJ45 to M12 D Coded Cable
RX- (GREEN)
TX+
(WHITE/ORANGE)
RX+ (WHITE/GREEN)
TX- (ORANGE)
STRAIGHT-THROUGH
CABLE
M12 D Coded to M12 D Coded Cable
RX- (GREEN)
6
3
2
1
RX- (GREEN)
RX+ (WHITE/GREEN)
TX- (ORANGE)
TX+ (WHITE/ORANGE)
MALE
RX+ (WHITE/GREEN)
TX- (ORANGE)
RX- (GREEN)
TX+ (WHITE/ORANGE)
MALE
2
3
4
1
RX+ (WHITE/GREEN)
TX- (ORANGE)
RX- (GREEN)
TX+ (WHITE/ORANGE)
2
3
4
1
MALE
