G3 Output modules incorporate short circuit protection and diagnostics to identify short circuit, open coils and over
temperature conditions. The diagnostics can be accessed within the user PLC program or the G3 Ethernet/IP
TM
node’s
integrated webpage. Detailed information regarding these features can be found on page 157.
Output Type
Output
State
Fault Condition
Status
Bit
Valve Solenoid Coil Driver
ON
No Fault
0
Fault - Short Circuit, Over Temp/Over Current
1
Valve Solenoid Coil Driver
OFF
No Fault
0
Fault - Open Load
1
Discrete Outputs
ON
No Fault
0
Fault - Short Circuit, Over Temp/Over Current
1
