5.9.2.1 Removing the developer station
A29246-X20-X-4-7680 / fa509.fm 147
5. Hold developer station by the handle
and pull out approx. 30 cm.
6. Remove vacuum hose.
7. Remove toner suction hose from toner
box.
8. Mount the toner suction hose and vacuum hose in the rubber mounting above the
fine filter.
Proceed as follows:
