7.2.4 Replacing the developer
240 A29246-X20-X-4-7680 / fa701.fm
7. Turn the turning knob to the left and
swivel off the fan from the developer
station.
8. Pull out the lid from the developer
station vacuum opening.
9. Remove vacuum hose from the toner
box and insert in developer station
vacuum opening. Ensure that the
noses on the handle lie in the vacuum
opening guides.
Proceed as follows:
2 of 5
To Next Page
