7.2.4 Replacing the developer
A29246-X20-X-4-7680 / fa701.fm 241
10. Move the lever to the right.
11. Click on the following button to start the developer replacement:
The developer is automatically extracted.
12. Repeat as needed. Click the following button on the operator panel:
If the developer has already been completely removed, click the following button:.
13. Move the lever to the left.
Proceed as follows:
