45530603TH Rev.2
4-61
Oki Data CONFIDENTIAL
4. TROUBLESHOOTING PROCEDURE
(13) Put the output unit back into the printer.
(11) Hold the fuser unit’s handle with both hands and set to the output unit.
Note ! Check the inside of the printer for remaining paper and then set the fuser unit.
(10) Set to the output unit and attach the screw.
Note! Pay attention to don't drop into the printer when attach the screws.
(12) Push down the fuser unit’s lock lever (blue).
To Next Page
