45530603TH Rev.2
6-60
Oki Data CONFIDENTIAL
6. REPLACEMENT OF PARTS
㉜
45240001PA Roller-Assy-Offset
㉝
45264701PA Box-Assy-Waste
Class C
Apply a normal amount of MOLYKOTE
(EM-30LP) to the gear
Class D
Apply a normal amount of FLOIL(GE-334C)
35mm from the end of shaft
Class D
Apply a normal amount of FLOIL(GE-334C)
35mm from the end of shaft
Apply a HARVES to hatched portion (by brush)
Apply a HARVES
Apply a HARVES
Bush
Gear-Drive_Z20
Callar-Stacker
35mm
35mm
GEAR-SPIRAL
