Oki C911 - Page 260

45530603TH Rev.2
6-61
Oki Data CONFIDENTIAL
6. REPLACEMENT OF PARTS
㉞
451705XX Plate-Base-Assy
(
Same as Option-Tray/LCF/Caster-Tray)
㉟
45182601 Cover Assy-TC(2 sets)
Apply a HARVES to inside
of the hole and R portion
(by brush)
Class C
Apply a normal amount of
MOLYKOTE (EM-D110) to this portion (Frame-SP)
Frame-Hinge-TC
Bracket-Hinge-TC
Frame-SP
Shaft-Hinge
