45530603TH Rev.2
2-14
Oki Data CONFIDENTIAL
2. DESCRIPTION OF OPERATION
Counter specifications
Total page
count
MPT page
count
Tray 1 page
count
Tray 2 page
count
Tray 3 page
count
Tray 4 page
count
Tray 5 page
count
Color page count
Monochrome
page count
Description Total number
of prints
Number of
print media
hopped from
MPT
Number of
print media
hopped from
Tray 1
Number of
print media
hopped from
Tray 2
Number of
print media
hopped from
Tray 3
Number of
print media
hopped from
Tray 4
Number of
print media
hopped from
Tray 5
Total number of color prints Total number of
monochrome prints
Count method:
A4-basis or size
independence
Count up
after passing
the IN3
sensor
Count up if
MPF (MPT)
hopping
is finished
successfully
Count up
if Tray 1
hopping
is finished
successfully
Count up
if Tray 2
hopping
is finished
successfully
Count up
if Tray 3
hopping
is finished
successfully
Count up
if Tray 4
hopping
is finished
successfully
Count up
if Tray 5
hopping
is finished
successfully
The number of print media
passing the fuser in color
mode is counted up when
each job is finished. (*1)
The value is counted on an
A4/Letter basis. Refer to
A4/Letter conversion table
(on the next page).
The number of print
media passing the fuser
in monochrome mode is
counted up when each job
is finished. (*1)
Printing speed for color
mode may be applied to
monochrome mode. The
value is counted on an A4/
Letter basis. Refer to A4/
Letter conversion table (on
the next page).
Operation when
paper has jammed
Printed pages are not counted when a paper feed (hopping) jam or a feed jam (code 380) occurs.
Printed pages are counted when any jam except the said jams occurs.
Since the total number of prints is counted up when the front end of print media passes the writing sensor, a
feed jam (code 380) is also included into the limits for counted according to its jam type.
Printed pages are not counted if paper jams before
passing the fuser. They are counted if prints jam after
passing the fuser.
Operation for
Duplex
Front/back
count
(+2)
Only front count (+1) The count increases by two.
If a color page and a monochrome page exist in a pair of
two pages, the color page count increases by one and
the monochrome page count increases by one. If color
pages exist in a pair of two pages, the color page count
increases by two. If monochrome pages exist in a pair of
two pages, the monochrome page count increases by two.
Reset condition None None
Value storage
destination
PU PU PU PU PU PU PU CU CU
Menu / MenuMap
output
Engine MenuMap
output
(*2) (*2) (*2) (*2) (*2) (*2) - -
*1 The count is updated every four pages or at the completion of the printing job, but the count is not updated if the power is turned off when printing any page of page 1 to 3 of a printing job
having more than four pages.
*2 Engine MenuMap outputs Engine Menu Print (the first page) and Engine EEPROM Dump Print (the last page), and the number of sheets of paper fed from each tray is described only in the
latter one (Dump display only).
