Oki C911 Maintenance Manual

45530603TH Rev.2
2-15
Oki Data CONFIDENTIAL
2. DESCRIPTION OF OPERATION
Counter specifications (Spot color only)
Spot color 1 Spot color 2
Definition Total number of prints in
combination of spot color and
other colors
Total number of prints using spot
color only
Count method:
A4-basis or size
independence
The number of print media is counted up when each job is finished.
The value is counted on an A4/Letter basis. Refer to A4 / Letter
conversion table (on the next page).
Dealing when paper
has jammed
If paper jams occur before passing the fuser is recovery. Therefore
the printed pages are not counted.The printed pages are counted if
paper jams occur after passing the fuser.
Dealing for Duplex
printing
The count is increased by two.
In the case of the printing of both-side are used the Spot color 1
or the Spot color 2 in Duplex printing, the printing number for each
categories is increased by two.
On the other hand, in the case of the printing of one-side is used
the Spot color 1 or the Spot color 2 in Duplex printing, the printing
nunber for each categories is increased by one. After all, in the case
of the each pages is printed by different Spot color number in Duplex
printing, the printing number in the target category is increased by
one.
Reset condition None
Value storage
destination
CU CU
Menu/MenuMap
output
EngineMenuMap
output
- -
