45530603TH Rev.2
4-44
Oki Data CONFIDENTIAL
4. TROUBLESHOOTING PROCEDURE
(6) If there is no remaining paper in the fuser unit, pull up the fuser unit’s lock lever (blue). (3) If there is remaining paper in the fuser unit, pull up the fuser unit’s jam release
levers (blue).
(4) Ensure to slowly pull the remaining paper in the opposite direction from the paper
feeding direction.
(5) Push down the fuser unit’s jam release levers (blue).
(7) Hold the fuser unit’s handle with both hands and remove the unit onto a flat surface.
(8) Remove the remaining paper.
To Next Page
