Chapter 12 118
2In DIN2/
Preset2
Digital input 2/preset
axis 2.
Programmable input. Can
be configured as generic
input 2, or as the preset of
encoder 2. Refer to the
OmniScan software user’s
manuals (“Configuring the
Digital Input” section) for
information on
programming this input.
To preset, you must use a
high-level signal with a
minimum signal length of
50 ms.
TTL
3 Out +5 V External power supply 500 mA
4In AINAnalog input ±5V
5In DIN3/
AcqEn
Digital input 3/acquisition
enable.
Programmable input. Can
be configured as generic
input 3, or as an
acquisition-enabled signal
(enabled at a high level
with a minimum signal
length of 50 ms). By default,
configured as generic
input 3. Refer to the
OmniScan software user’s
manuals (“Configuring the
Digital Input” section) for
information on
programming this input.
TTL
Table 25 Pinout for the scanner interface connector (continued)
Pin I/O Signal Description Current Level
