Error Table
154
FQ-CR2 User’s Manual
9-1 Error Table
Error History
Up to 10 errors will be stored in the error history in the Sensor or Touch Finder.
This section describes the causes of and measures for errors that are stored in the error history.
Errors Stored in the Error History
If an error that is indicated by this icon occurs, the ERROR operation indicator will light and the ERROR signal will turn ON.
Error in error history Cause Points to check Measures to perform
TRIG input error
(Error code: 01040302)
The TRIG signal was input while
the BUSY signal was ON.
• Check the program in the
PLC or other host to see if an
interlock or similar measure
has been implemented.
• If a relay or other device with
contacts is being used as the
input device, see if chattering
has occurred.
• Program interlocks to control
the TRIG and IN5 input sig-
nals so that they do not turn
ON while the BUSY signal is
ON.
•Switch from a device with
contacts (e.g., relay) to a
device without contacts (e.g.,
SSR or PLC transistor out-
put).
IN input error
(Error code: 11020900)
The IN5 signal was input while
the BUSY signal was ON.
Scene data error
(Error code: 01030800)
The scene could not be
switched for an input signal from
an external device.
--- The scene data to be switched
to is corrupted.
Reset the scene data from the
beginning.
Logging error
(Error code: 02160702,
02160703)
All of the data was not saved
when logging data to a file.
Check to see if the BUSY output
parameter is set to Measure-
ment.
Set the BUSY output parameter
to Data logging or Image log-
ging.
SD card output error
(Error code: None)
A write to the SD card failed. Check to see if the SD card is
locked. Check to see if there is
sufficient space available on the
SD card.
Unlock the SD card. Delete
unnecessary files from the SD
card.
