Outputting/Controlling with Ethernet
FQ-CR2 User’s Manual
141
8
Communications with External Devices
● ITEMDATA or ID
Acquire Inspection Item Data
This command acquires the parameters and measurement values of the specified inspection item.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Inspection item number Specifies the inspection item number. (0 to 31)
External reference data
number
Specifies the external reference data number. (0 to 999)
Refer to 10-2 External Reference Parameters (p. 168) for details.
Acquired value Returns the data for the specified inspection item.
Refer to 10-2 External Reference Parameters (p. 168) for details.
IT DATA
CR
EM
Inspection item number
(2 digits max.)
Command
Space
(0×20)
Space
(0×20)
Delimiter
Command
or
DI CR
Delimiter
Space
(0×20)
Space
(0×20)
External reference
data number
(3 digits max.)
Inspection item
number
(2 digits max.)
External reference
data number
(3 digits max.)
CR
Acquired
value
Delimiter
CR OK
CR ER
Delimiter
