External Reference Parameters
168
FQ-CR2 User’s Manual
10-2 External Reference Parameters
2D Codes
External
reference
number
Data name Set/acquired Data range Default Text string
assigned to
Ethernet
output
setting
Logged
0 Judgment Acquired only -2: No judgment (not inspected)
0: Judgment result OK
-1: Judgment result NG
-13: Teaching not executed error
-14: Figure not registered error
-15: Outside region error
-16: Inspection timeout error
-2 JG
---
5 Num. of char. Acquired only 0 to 1024 0 N ---
6
*1
Characters Acquired only Text string --- --- ---
8 Cell Recog. Rate Acquired only 0 to 100 0 E Logged
9 Contrast Acquired only 0 to 100 0 C ---
10 Focus Acquired only 0 to 100 0 F ---
120 Code type Set/acquired 0: Auto
1: DataMatrix
2: QR Code
0 ---
---
121 Code color Set/acquired 0: Auto
1: Black
2: White
0 --- ---
122 Cell (DataMatrix
Square)
Set/acquired 0: Auto
1: 10 × 10
2: 12 × 12
...
16: 64 × 64
0 ---
---
123 Cell (DataMatrix
Rectangle)
Set/acquired 0: Auto
1: 8 × 18
2: 8 × 32
...
16: 16 × 64
0 ---
---
124 Cell (QR Code) Set/acquired 0: Auto
1: 21 × 21
2: 25 × 25
...
10: 57 × 57
0 ---
---
127 Size Set/acquired 50 to 480 480 --- ---
128 Reverse Set/acquired 0: Auto
1: Normal
2: Reverse
0 --- ---
129 QR Code Model Set/acquired 0: Auto
1: Model 1
2: Model 2
0 --- ---
130 Error Correction
Level
Set/acquired 0: Auto
1: M (15%)
2: L (7%)
3: H (30%)
4: Q (25%)
0 ---
---
132 Fast mode Set/acquired 0: OFF 1: ON 0 --- ---
133 String output on/off Set/acquired 0: OFF 1: ON 0 --- ---
134 Partial output on/off Set/acquired 0: OFF 1: ON 0 --- ---
