Specifications and Dimensions
170
FQ-CR2 User’s Manual
10-3 Specifications and Dimensions
Sensor
Specifications
Item Fixed Mount 2D Code Reader
Model NPN FQ-CR20@@@@-M
PNP FQ-CR25@@@@-M
Field of view Refer to Table 1.
Installation distance Refer to Table 1.
Minimum resolution FQ-CR2@010F-M: 0.040 mm FQ-CR2@050F-M: 0.070 mm
FQ-CR2@100F-M: 0.282 mm FQ-CR2@100N-M: 0.155 mm
Main functions Inspection items 2D codes (DataMatrix (EC200), QR codes)
Number of simulta-
neous measure-
ments
32
Number of registered
scenes
32
Image input Image filter High dynamic range (HDR), polarizing filter (attachment), Smooth, Dilate, Erosion,
Median
Image elements 1/3-inch monochromatic CMOS
Shutter 1/250 to 1/32,258
Processing resolu-
tion
752 × 480
Lighting Lighting method Pulse
Lighting color White
Data logging Measurement data In Sensor: 1,000 items (If a Touch Finder is used, results can be saved up to the capac-
ity of an SD card.)
Images In Sensor: 20 images (If a Touch Finder is used, images can be saved up to the capacity
of an SD card.)
Measurement trigger External trigger (single or continuous)
I/O specifications Input signals 7 signals
• Single measurement input (TRIG)
• Control command input (IN0 to IN5)
Output signals 3 signals
• Control output (BUSY)
• Overall judgement output (OR)
• Error output (ERROR)
Note: The three output signals can be allocated for the judgements of individual inspec-
tion items.
Ethernet specifica-
tions
100Base-TX/10Base-T
Numerical outputs and control commands are supported with no-protocol communica-
tions.
Input specifications Refer to Table 2.
Output specifications
Connection method Special connector cables
Power supply and I/O: 1 cable (FQ-WD@@@)
Touch Finder and computer: 1 cable (FQ-WN@@@)
