Auto Focus Multi Code Reader V430-series User’s Manual (Z392) A-17
Appendices
Optics Options (sold separately)
Front Window (for replacement)
V430-AF0
Diffuser
V430-AF1
Diffuser spreads out light.
Diffuser reduces direct reflection of LEDs.
Polarizer
V430-AF2
Polarizer reduces glare from specular objects.
Polarizer passes light from diffuse objects.
Specular (Vertical) Reflections are filtered out. Only Horizontal component of Diffuse Reflections
make it to the camera.
Accessories:
Gasket(1)
Phillips-Head Screws(4)
Accessories:
Gasket(1)
Phillips-Head Screws(4)
With Diffuser
Without Diffuser
Accessories:
Gasket(1)
Phillips-Head Screws(4)
With PolarizerWithout Polarizer
