Auto Focus Multi Code Reader V430-series User’s Manual (Z392) A-21

Appendices

Installation method

In case of side installation

In case of base installation

Phillips-head screw

M3x6P=0.5mm

Mounting bracket

Washer

Mounting holes

Washer

Phillips-head screw

M3x6P=0.5mm

Mounting bracket
