Verify PS Backplane Functionality
7.
Reconnect the ribbon cable from the motherboard to the PS backplane (panel 3).
8.
Reinstall the air divider by sliding it into the chassis.
9.
Reinstall the memory risers.
See “Install a DIMM and a Memory Riser” on page 106.
10.
Push the power supplies all the way back into the chassis.
See “Install a Power Supply” on page 93.
11.
Return the server to operation.
a.
Install the top cover.
See “Replace the Top Cover” on page 169.
b.
Return the server to the normal operating position.
See “Return the Server to the Normal Operating Position” on page 170.
c.
Reinstall the power cords to the power supplies and power on the server.
See “Returning the Server to Operation” on page 169.
Related Information
■
“Remove the PS Backplane” on page 163
■
“Verify PS Backplane Functionality” on page 167
Verify PS Backplane Functionality
1.
Use the Oracle ILOM show faulty command to verify that the fault has been
cleared.
See “Check for Faults” on page 46 for more information on using the show faulty command.
2.
Perform one of the following tasks based on your verification results:
■
If the previous steps did not clear the fault, see “Detecting and Managing Faults” on page 31
for information about the tools and methods you can use to diagnose component faults.
■
If the previous steps indicate that no faults have been detected, then the component has been
replaced successfully. No further action is required.
Servicing the PS Backplane 167
