Attachment of Devices During Service
Related Information
■
“Replace the Top Cover” on page 169
Attachment of Devices During Service
During service procedures, you might have to connect devices to the server.
■
For OS support, connect an Ethernet cable to the one of the Ethernet connectors (NET 0,
NET 1, NET 2, and NET 3).
■
If you plan to interact with the system console directly, you can connect additional external
devices, such as a mouse and keyboard, to the server's USB connectors, and connect a
monitor to a HD-15 video connector. The rear HD-15 video connector is active by default.
For more details on selecting an active video port, refer to Server Installation.
■
If you plan to connect to the Oracle ILOM software over the network, connect an Ethernet
cable to the Ethernet port labeled NET MGT.
Note - The service processor (SP) uses the NET MGT (out-of-band) port by default. You
can configure the SP to share one of the sever's four Ethernet ports instead. The SP uses
only the configured Ethernet port.
■
If you plan to access the Oracle ILOM CLI through the management port, connect a serial
null modem cable to the RJ-45 serial port labeled SER MGT.
■
The USB connectors on the front panel support USB 2.0. The USB connectors on the rear
panel support USB 3.0.
Related Information
■
“Front Panel Components (Service)” on page 13
■
“Rear Panel Components (Service)” on page 15
■
“Detecting and Managing Faults” on page 31
■
Server Installation
68 SPARC T5-2 Server Service Manual • February 2017
