Component Task Reference
Related Information
■
“Component Service Categories” on page 57
■
“Internal Component Locations” on page 17
■
“Motherboard Component Locations” on page 21
■
“I/O Component Locations” on page 22
■
“Power Distribution and Fan Module Component Locations” on page 24
Component Task Reference
This table lists the names of serviceable components. This table also lists the Oracle ILOM
target and the task location for each component. Components not present on the 1-processor
server are marked with an asterisk (*).
Component Oracle ILOM Target Links
Battery
/SYS/MB/BAT
“Servicing the Battery” on page 117
DIMMs
/SYS/MB/CMn/CMP/MRn/BOBn/CHn/D0
“Servicing Memory Risers and
DIMMs” on page 97
Drive backplane
/SYS/SASBP
“Servicing the Drive
Backplane” on page 157
Drives
/SYS/SASBP/HDD0 (bottom)
/SYS/SASBP/HDD1
/SYS/SASBP/HDD2
/SYS/SASBP/HDD3
/SYS/SASBP/HDD4
/SYS/SASBP/HDD5 (top)
“Servicing Drives” on page 69
DVD drive
/SYS/SASBP/DVD
“Servicing the DVD
Drive” on page 113
Fan board
/SYS/FANBD
“Servicing the Fan
Board” on page 135
Fan modules As viewed from front of server:
/SYS/FANBD/F0 (left front)
/SYS/FANBD/F1 (center front)
/SYS/FANBD/F2 (right front)
/SYS/FANBD/F3 (left rear)
“Servicing Fan
Modules” on page 81
28 SPARC T5-2 Server Service Manual • February 2017
