Remove a Drive Filler Panel
a.
Push the release button to open the latch.
b.
Unlock the drive by moving the latch to the right.
c.
Grasp the latch and pull the drive out of the slot.
Caution - When you remove a drive, replace it with a filler panel or another drive. Otherwise,
the server might overheat due to improper airflow.
8.
Install a replacement drive or a drive filler panel.
See “Install a Drive” on page 76 or “Install a Drive Filler Panel” on page 77.
Related Information
■
“Install a Drive” on page 76
■
“Remove a Drive Filler Panel” on page 74
■
“Install a Drive Filler Panel” on page 77
■
“Verify Drive Functionality” on page 78
Remove a Drive Filler Panel
A customer can perform this procedure while the server is running. See “Component Service
Categories” on page 57 for more information about hot-service procedures.
1.
Attach an antistatic wrist strap.
