Fan Module LEDs

LED Color Status When Lit

Power OK Green The server is powered on and the fan module is

functioning correctly.

Service Required Amber The fan module is faulty.

Related Information

■

“Locate a Faulty Fan Module” on page 83

■

“Detecting and Managing Faults” on page 31
