Memory Riser and DIMM FRU Names
Memory Riser Label Memory Riser or DIMM FRU Name Ejector
Color
Slot Body
Color
CM0/MR0
(Farthest from power
supplies)
/SYS/MB/CM0/CMP/MR0 (riser)
/SYS/MB/CM0/CMP/MR0/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR0/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR0/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR0/BOB1/CH1/D0

Black
Black
White
White

Black
White
Black
White
CM0/MR1
/SYS/MB/CM0/CMP/MR1 (riser)
/SYS/MB/CM0/CMP/MR1/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR1/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR1/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR1/BOB1/CH1/D0

Black
Black
White
White

Black
White
Black
White
CM0/MR2
/SYS/MB/CM0/CMP/MR2 (riser)
/SYS/MB/CM0/CMP/MR2/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR2/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR2/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR2/BOB1/CH1/D0

Black
Black
White
White

Black
White
Black
White
CM0/MR3
/SYS/MB/CM0/CMP/MR3 (riser)
/SYS/MB/CM0/CMP/MR3/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR3/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR3/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR3/BOB1/CH1/D0

Black
Black
White
White

Black
White
Black
White
CM1/MR0
(Not on the 1-processor
server.)
/SYS/MB/CM1/CMP/MR0 (riser)
/SYS/MB/CM1/CMP/MR0/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR0/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR0/BOB1/CH0/D0
/SYS/MB/CM1/CMP/MR0/BOB1/CH1/D0

Black
Black
White
White

Black
White
Black
White
CM1/MR1
(Not on the 1-processor
server.)
/SYS/MB/CM1/CMP/MR1 (riser)
/SYS/MB/CM1/CMP/MR1/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR1/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR1/BOB1/CH0/D0

Black
Black
White

Black
White
Black
98 SPARC T5-2 Server Service Manual • February 2017
