I/O Component Locations

Related Information

■

“Component Service Categories” on page 57

■

“Servicing Memory Risers and DIMMs” on page 97

■

“Servicing the Motherboard” on page 141

■

“Servicing the Battery” on page 117

I/O Component Locations

No. Component Oracle ILOM Target LInks

1 Drives

/SYS/SASBP/HDD0 (bottom)

/SYS/SASBP/HDD1

/SYS/SASBP/HDD2

/SYS/SASBP/HDD3

“Servicing

Drives” on page 69

22 SPARC T5-2 Server Service Manual • February 2017
